>>>>>型號:5SHY4045L0001 3BHB018162R0001 集成柵極換流晶閘管

【功能描述】

5SHY4045L0001 3BHB018162R0001集成柵極換流晶閘管

5SHY4045L0001 3BHB018162R0001是將GTO芯片與反并聯二極管和柵極驅動電路集成在一起，再與其柵極驅動器在外圍以低電感方式連接,結合

了晶體管的穩定關斷能力和晶閘管低通態損耗的優點，在導通階段發揮晶閘管的性能，關斷階段呈現晶體管的特性。

IGCT(Intergrated Gate Commutated Thyristors)是1996年問世的用于巨型電力電子成套裝置中的新型電力半導體器件。IGCT是一 種基于GTO結構、利用集成柵極結構進行柵極硬驅動、

采用緩沖層結構及陽極透明發射極技術的新型大功

半導體開關器件，具有晶閘管的通態特性及晶體管的開關特性。5SHY4045L0001 3BHB018162R0001由于采用了緩沖結構以及淺層發射極技術,

因而使動態損耗降低了約50%，另外，此類器件還在一個芯片 上集成了具有良好動態特性的續流二極管，從而以其獨特的方式實現了晶閘管的低通態

壓降、高阻斷電壓和晶體管穩定的開關特性有機結合.

IGCT使變流裝置在功率、可靠性、開關速度、效率、成本、重量和體積等方面都取得了巨大進展，給電力電子成套裝置帶來了新的飛躍。

>>>>>型號:5SHY4045L0001 3BHB018162R0001 集成柵極換流晶閘管

【英文介紹】

5SHY4045L0001 3BHB018162R0001 Integrated gate converter thyristor

5SHY4045L0001 3BHB018162R0001 Integrated GTO chip with anti-parallel diode and gate driver

circuit, and then connected with the gate driver in a low inductance mode at the periphery, combined

Due to the advantages of stable switching ability of transistor and low on-state loss of thyristor, the performance of thyristor is brought into play in on-stage, and the

characteristics of transistor are presented in off-stage.

IGCT(Intergrated Gate Commutated Thyristors) is a new type of power semiconductor device used in large power electronics packages introduced in 1996. IGCT is a new

type of power based on GTO structure, using integrated gate structure to drive the gate hard, using buffer layer structure and transparent anode emitter technology

The semiconductor switching device has the on-state characteristics of a thyristor and the switching characteristics of a transistor. 5SHY4045L0001 3BHB018162R0001

Due to the buffer structure and shallow emitter technology,

Thus, the dynamic loss is reduced by about 50%. In addition, such devices also integrate a continuous current diode with good dynamic characteristics on a chip, so as

to achieve the low-pass state of the thyristor in its unique way

The voltage drop, high blocking voltage and stable switching characteristics of the transistor are combined.

IGCT has made great progress in power, reliability, switching speed, efficiency, cost, weight and volume, and has brought a new leap to power electronic complete sets.
