216EA61B HESG448230R1/G | 高壓直流變流閥模塊 | CI854AK01 3BSE030220R1
型號：216EA61B HESG448230R1/G
類別：高壓直流變流閥模塊
毛重:0.54 kg
保障：365天
發貨：3-5天/周
A端電壓：400V
B端電壓：200V
C端電壓：120V
高壓側最大電流：20A
額定輸出功率：2KW
最大效率：>94%
直流穩壓精度：1%
直流穩流精度：1%
216EA61B HESG448230R1/G 高壓直流變流閥模塊是電力系統中重要的組成部分，特別是在特高壓直流輸電技術(HVDC)中，它扮演著核心設備的角色。以下是關于高壓直流變流閥模塊的一些關鍵信息：
主要組成部分：
晶閘管級：這是特高壓直流換流閥模塊的主要部分之一，由多個晶閘管或二極管組成，用于控制電流的導通和關斷。
飽和電抗器：其作用是抑制流過晶閘管電流的變化率，限制晶閘管產生的電壓，提高晶閘管換流閥分布電壓的均勻性。
阻容均壓回路(對于串聯IGBT高壓直流換流閥)：與飽和電抗器的作用相似，用于抑制IGBT兩端電壓的變化率，提高IGBT換流閥分布電壓的均勻性。
工作原理：
216EA61B HESG448230R1/G 輸入端通常是三相交流電源，經過橋式整流器(由晶閘管或二極管組成)將交流電轉換為直流電。
為了減少直流電壓中的脈動成分，通常會在直流電路中添加濾波器，由電容器和電感器組成，幫助平滑直流電壓。
應用場景：
特高壓直流輸電：216EA61B HESG448230R1/G 是長距離、大容量的電力輸送的理想選擇，特別適用于海底電纜和遠距離輸電等情況。高壓直流變流閥模塊通過將交流電轉換為直流電，在長距離輸電中降低輸電損耗和電力傳輸損失。
Model: 216EA61B HESG448230R1/G
Category: HVDC converter module
Gross weight :0.54 kg
Guarantee: 365 days
Delivery: 3-5 days/week
A terminal voltage: 400V
B terminal voltage: 200V
C terminal voltage: 120V
Maximum current on the high voltage side: 20A
Rated output power: 2KW
Maximum efficiency: >94%
Dc voltage regulation accuracy: 1%
Dc steady current accuracy: 1%
216EA61B HESG448230R1/G HVDC converter module is an important part of the power system, especially in the UHVDC transmission technology (HVDC), it plays the role of the core equipment. Here are some key information about the HVDC converter module:
Main components:
Thyristor stage: This is one of the main parts of the UHV DC converter valve module and consists of multiple thyristors or diodes to control the on-off and off-off of the current.
Saturation reactor: Its function is to inhibit the rate of change of the current flowing through the thyristor, limit the voltage generated by the thyristor, and improve the uniformity of the voltage distribution of the thyristor converter valve.
Resistive-capacitance voltage equalizing circuit (for series IGBT high voltage DC converter valve) : similar to the role of saturated reactor, used to suppress the change rate of the voltage at both ends of the IGBT, improve the uniformity of the distributed voltage of the IGBT converter valve.
How it works:
The 216EA61B HESG448230R1/G input is usually a three-phase AC power supply, which is converted from AC to DC by a bridge rectifier (consisting of a thyristor or diode).
To reduce the pulsating component of the DC voltage, filters are usually added to the DC circuit, consisting of capacitors and inductors, to help smooth the DC voltage.
Application scenario:
Uhvdc transmission: 216EA61B HESG448230R1/G is ideal for long-distance, large-capacity power transmission, especially for submarine cables and long-distance transmission. The HVDC converter module reduces transmission losses and power transmission losses in long-distance transmission by converting alternating current to direct current.
