500SCM01 1MRB200059/C 1MRB15004R0001 |星形耦合器模塊
型號:500SCM01 1MRB200059/C 1MRB15004R0001
分類:星型耦合器模塊
額定電流:1A
額定電壓:230V AC
控制方式:開環控制
過載保護、欠壓保護、過壓保護、短路保護等
通訊接口RS232、RS485
尺寸:100 × 50 × 40毫米
重量:0.5公斤
500SCM01 1MRB200059/C 1MRB15004R0001星形耦合器模塊是光纖通信設備的重要部件，具有特定的功能和結構特點。下面是星形耦合器模塊的詳細說明:
定義:
500SCM01 1MRB200059/C 1MRB15004R0001星形耦合器是一種n×m型耦合器，其作用是將n根光纖輸入的光功率合并后均勻分配到m根光纖上。這里n和m不一定相等，所以星型耦合器常被用作多端分配器。
結構與制造:
星形耦合器可采用雙錐熔接成形技術制造，尤其適用于多模光纖系統。星形耦合器可以由幾根獨立的多模光纖相互合并并熔化拉伸制成。
對于單模光纖系統，星形耦合器可以通過級聯l×2耦合器制成。
類型:
傳輸型星形耦合器:當電源輸入到耦合器一側的任何端口時，電源將被傳輸?shù)搅硪粋?cè)的所有端口。理想情況下，耦合器的相同側端口彼此隔離。
反射星形耦合器:將光從任何端口耦合到耦合器的所有端口。
特點:
無源器件:500SCM01 1MRB200059/C 1MRB15004R0001星形耦合器通常是無源的，這意味著它們不需要外部電源來工作。與有源器件相比，無源器件具有高可靠性和低成本的特點。
靈活性:通過星形耦合器，光源的輸出光功率可均勻分布到所有接收站點，為分布式網絡提供靈活性。
500SCM01 1MRB200059/C 1MRB15004R0001 | Star coupler module
Model: 500SCM01 1MRB200059/C 1MRB15004R0001
Category: Star coupler module
Rated current: 1A
Rated voltage: 230V AC
Control mode: open loop control
Protection function Overload protection, undervoltage protection, overvoltage protection, short circuit protection, etc
Communication ports RS232, RS485
Dimensions: 100 x 50 x 40 mm
Weight: 0.5kg
500SCM01 1MRB200059/C 1MRB15004R0001 Star coupler module is an important optical fiber communication equipment component, with specific functions and structural characteristics. Here is a detailed explanation of the star coupler module:
Definition:
The 500SCM01 1MRB200059/C 1MRB15004R0001 star coupler is an n×m coupler whose function is to combine the optical power input from n optical fibers and then evenly distribute it to m optical fibers. Here n and m are not necessarily equal, so star couplers are often used as multiterminal power dividers.
Structure and Manufacture:
Star couplers can be manufactured by fused double cone forming technology, especially for multimode fiber optic systems. The star coupler can be made by merging several independent multimode fibers with each other and melting stretching.
For single-mode optical fiber systems, star couplers can be made by cascading l×2 couplers.
Type:
Transmission type star coupler: When power is input to any port on one side of the coupler, power is transmitted to all ports on the other side. Ideally, the same side ports of the coupler are isolated from each other.
Reflective star coupler: Coupling light from any port to all ports of the coupler.
Features:
Passive devices: 500SCM01 1MRB200059/C 1MRB15004R0001 Star couplers are usually passive, meaning they do not require an external power source to operate. Compared with active devices, passive devices have the characteristics of high reliability and low cost.
Flexibility: Through the star coupler, the output optical power of the light source can be evenly distributed to all receiving sites, providing flexibility for distributed networks.
