>>>>>型號:1900/65A 設備監視器是旨在持續監測和保護設備
【功能描述】
描述
1900/65A通用設備監視器是旨在持續監測和保護設備用于各種應用和行業。的
Monitor的低成本使其成為一般用途機器和過程的理想解決方案，可以從中受益持續監控和保護。輸入
1900/65A提供4個傳感器輸入和4個溫度輸入。軟件可以配置每個傳感器輸入支持2線和3線加速度計，速度傳感器或接近傳感器。每個溫度輸入支持E型，J型，K型和T型熱電偶，以及2線或3線rtd。輸出1900/65A提供6個繼電器輸出，4個4-20 mA記錄儀輸出，以及專用緩沖輸出。用戶可以用1900組態軟件配置繼電器嗎根據OK, Alert和任何航道或航道組合的危險狀況;并提供來自任何渠道的任何變量的數據記錄器輸出。專用緩沖區輸出可以提供每個換能器輸入信號。
Modbus網關選項允許監視器提供靜態變量，狀態，事件列表，時間和日期信息
直接到任何Modbus客戶端，包括分布式控制系統(dcs)，監控和數據采集(SCADA)系統，可編程邏輯控制器，或系統1軟件。監視器使用一個內部計數器和一個Modbus客戶端/主端時間參考生成時間和日期信息。用戶可以升級監視器而不需要Modbus網關通過訂購1900/01進行通信1900/65A通用設備監視器
數據表
本特利內華達機械狀態監測
支持通過以太網進行Modbus通信
和一個軟件可配置的RS232/485串行
端口。
配置
用戶定義監控操作和
Modbus網關由注冊表映射使用
在筆記本電腦或個人電腦上運行的軟件
配置文件，下載到
監視器通過內置的以太網
連接。1900/65A永久存儲
非易失性的配置信息
內存，并可以將此信息上傳到
PC進行更改。
顯示模塊
1900/65A可選支持
顯示/鍵盤查看通道信息或
進行一些小的配置更改。這允許
1900/65A作為獨立操作
包中。如果需要，用戶可以掛載
顯示距離最遠75米(250英尺)
監控模塊。
>>>>>型號:1900/65A 設備監視器是旨在持續監測和保護設備
【英文介紹】
Description
The 1900/65A Universal Device monitor is
Designed for continuous monitoring and protection of equipment
Used in a variety of applications and industries. the
Monitor's low cost makes it an ideal solution for general purpose machines and processes that can benefit from it
Continuous monitoring and protection.
input
The 1900/65A offers 4 sensor inputs and 4
Temperature input. Software can be configured for each sensor
Input supports 2-wire and 3-wire accelerometers, speeds
Sensor or proximity sensor. Each temperature input is supported
Type E, type J, type K and type T thermocouples, as well as 2-wire or 3-wire RTDS.
exportation
The 1900/65A offers six relay outputs, four 4-20 mA
Recorder output, and dedicated buffer output. user
Can you configure relays with 1900 configuration software
According to OK, Alert and
Hazardous condition of any channel or combination of channels;
And provide data on any variable from any channel
Recorder output. Dedicated buffer output can be provided
Each transducer input signal.
The Modbus gateway option allows the monitor to provide
Static variables, states, event lists, time and date information
Direct to any Modbus client, including distributed control
Systems (dcs), monitoring and data acquisition
(SCADA) system, Programmable logic Controller (plc), or
System 1 software. The monitor uses an internal counter and a
Modbus Client/primary time Refer to the generation time and
Date information. Users can upgrade the monitor without the need
The Modbus gateway communicates by ordering 1900/01
Upgrade (see Ordering Information section). The 1900/65A
Document :173401
Start T
1900/65A Universal device monitor
Data sheet
Bentley Nevada mechanical condition monitoring
Supports Modbus communication over Ethernet
And a software configurable RS232/485 serial
Port.
disposition
User-defined monitoring operations and
The Modbus gateway is used by the registry map
Software that runs on a laptop or personal computer
Configuration file, download to
Monitor via built-in Ethernet
Connect. 1900/65A Permanent storage
Non-volatile configuration information
Memory and can upload this information
The PC changes.
Display module
1900/65A Optional
Display/Keyboard View channel information or
Make some minor configuration changes. This allows
1900/65A as a standalone operation
It's in the bag. If necessary, the user can mount it
Display distance up to 75 m (250 ft)
Monitoring module.
