177230-01-02-CN |5SHY5045L0020|振動變送器|
177230-01-02-CN 是 Bently Nevada 公司生產的一種振動變送器，它是一種簡單、循環供電的設備，可以快速且容易地安裝。這種變送器可以集成到與工廠資產狀況監測解決方案相連的可編程邏輯控制器 (PLC) 或控制系統中。它的設計簡單，有助于降低培訓、維護和服務的成本。變送器通過提供準確和可重復的數據，幫助更好地管理停機時間、優化維護計劃，并避免機械設備的不可預見的災難性故障 。
該變送器采用行業標準的 4 到 20 mA 循環供電發射機，并且具有多種環境耐受性，包括工作溫度范圍從 -40°C 到 +85°C。它還具有電氣隔離特性，隔離電阻大于 108 歐姆，隔離擊穿電壓為 600 Vrms 時漏電流小于 1 mA。此外，該變送器能夠承受最大加速度為 9.81 m/s2 的沖擊 。
技術參數包括：
電源電壓：12 到 30 Vdc，電流限制在 40 mA 以內。
安裝諧振頻率：大于 12 kHz。
橫向靈敏度：小于 5% 的靈敏度。
感測元件類型：陶瓷/剪切。
連接器接線規范：3 針 MIL-C-5015，316L 不銹鋼。
重量：大約 131 g。
直徑：25.4 mm。
高度：66.0 mm。
符合 FCC 規定，操作不受有害干擾影響，并且必須接受任何接收到的干擾
The 177230-01-02-CN is a vibration transmitter manufactured by Bently Nevada, Inc. It is a simple, cyclically powered device that can be installed quickly and easily. The transmitter can be integrated into a programmable logic controller (PLC) or control system connected to a plant asset condition monitoring solution. Its simple design helps to reduce the cost of training, maintenance and service. Transmitters help better manage downtime, optimize maintenance schedules, and avoid unforeseen catastrophic failures of machinery by providing accurate and repeatable data.
The transmitter uses industry standard 4 to 20 mA cyclically powered transmitters and has a variety of environmental tolerances, including operating temperatures ranging from -40°C to +85°C. It also has electrical isolation characteristics, isolation resistance greater than 108 ohms, isolation breakdown voltage of 600 Vrms leakage current less than 1 mA. In addition, the transmitter can withstand shocks with a maximum acceleration of 9.81 m/s2.
Technical parameters include:
Power supply voltage: 12 to 30 Vdc, current limited to 40 mA.
Installation resonant frequency: greater than 12 kHz.
Lateral sensitivity: Sensitivity of less than 5%.
Sensing element type: Ceramic/shear.
Connector wiring specification: 3-pin MIL-C-5015, 316L stainless steel.
Weight: Approximately 131 g.
Diameter: 25.4mm.
Height: 66.0mm.
In compliance with FCC regulations, the operation is free from harmful interference and must accept any received interference
