FBM42 | 內置診斷和故障檢測 | 高速數字輸入/輸出通道
型號：FBM42
產品參數:
一輸入電壓:24vdc
一輸出電壓:5vdc
一通信接口:RS485
一工作溫度:-40℃~ 70°C
尺寸:10cm x10cm x2cm
規格:
一高速數字輸入/輸出通道
一靈活的配置選項
一內置診斷和故障檢測
一易于安裝和維護
產品詳情:
FBM42 使用的模塊現場總線.
FBM42 接受來自冗余2Mbps現場總線的任何一條路徑(A或b)的通信--如果一條路徑出現故障或在系統級進行切
換，模塊將繼續通過有效路徑進行通信。
終端組件現場I/0信號通過以下方式連接到FBM子系統:0DIN導軌安裝終端組件(TA)，或口基板安裝TA。D使用聚酰胺(PA)
材料的壓縮螺桿式口使用聚酰胺(PA)材料的環形接線片區域的基板安裝TA可與使用聚碳酸酯/丙烯腈-丁二烯-苯乙烯(PC/ABS)材料的壓縮螺桿式端子一起使用?？刹鹦督K端電纜通過安裝FBM的底板上的現場連接器將DIN軌道安裝TA連接到FBM。終端電纜有以下材料:0聚氨酯D低煙無鹵(LSZH)。端接電纜有多種長度，長可達30米(98英尺)，允許將端接組件安裝在外殼或在相鄰外殼中。
輸入通道8個電阻式溫度檢測器(RTD)輸入通道。每個通道都是隔離和獨立的。
Model: FBM42
Product parameters:
One input voltage :24vdc
One output voltage :5vdc
Communication interface :RS485
A working temperature :-40℃~ 70°C
Size :10cm x10cm x2cm
Specifications:
A high speed digital input/output channel
A flexible configuration option
A built-in diagnosis and fault detection
Easy to install and maintain
Product Details:
Module fieldbus used by FBM42.
The FBM42 accepts communication from any path (A or b) of the redundant 2Mbps fieldbus - if a path fails or is cut at the system level
If not, the module will continue to communicate via a valid path.
The terminal assembly field I/0 signal is connected to the FBM subsystem by :0DIN rail mount Terminal Assembly (TA), or port substrate mount TA. D Use polyamide (PA)
Compression screw ports of materials Substrate mounting TA in the ring terminal area using polyamide (PA) material can be used with compression screw terminals using polycarbonate/acrylonitrile-butadiene-styrene (PC/ABS) material. The detachable terminal cable connects the DIN rail mounting TA to the FBM via a field connector on the baseplate where the FBM is mounted. The terminal cable is available in the following materials :0 polyurethane D Low smoke halogen free (LSZH). The end cable is available in a variety of lengths, up to 30 meters (98 ft) long, allowing the end component to be installed in the housing or in an adjacent housing.
Input channels Eight resistive temperature detector (RTD) input channels. Each channel is isolated and independent.
