>>>>>型號:IS200TBCIH21CD 接觸式輸入端子板

【功能描述】

IS200TBCIH21CD是一種接觸式輸入端子板，作為Mark VI系列中的一個組件。

Mark VI主要用于控制和自動化蒸汽和燃?xì)廨啓C(jī)操作。

IS200TBCIH21CD本質上是一種PCB（印刷電路板）。

它的表面包含許多電子元件，其中最顯著的是兩個大的黑色端子板，每個端子板包含24個端子，每個端子都標有白色數字1到48。這兩個端子板的右側是

一長串實心紅色mov或金屬氧化物變阻器，呈圓形。

在IS200TBCIH21CD的頂部中間可以找到兩個實心白色連接器，而沿著其右邊緣則是三個黑色和銀色插孔連接器端口，它們垂直對齊。

IS200TBCIH21CD的中心充滿了無數由銀金屬制成的小部件，它們看起來像非常小的矩形。

>>>>>型號:IS200TBCIH21CD 接觸式輸入端子板

【英文介紹】

The IS200TBCIH21CD is a contact input terminal board as a component in the Mark VI series.

The Mark VI is primarily used to control and automate steam and gas turbine operations.

The IS200TBCIH21CD is essentially a PCB (printed circuit board).

Its surface contains a number of electronic components, the most prominent of which are two large black terminal boards, each containing 24 terminals, each marked with white numbers

1 to 48. To the right of these two terminal boards is a long string of solid red mov or metal oxide rheostat in a circular shape.

Two solid white connectors can be found in the top middle of the IS200TBCIH21CD, while along its right edge are three black and silver jack connector ports that are aligned vertically.

The center of the IS200TBCIH21CD is filled with countless small parts made of silver metal that look like very small rectangles.
