>>>>>型號:DS200DCFBG1BNC 電源板 勵磁機和驅動器兼容

【功能描述】

DS200DCFBG1BNC 是為通用電氣的 Mark V 系列替換板和可選板制造的電源板。DS200DCFBG1BNC電路板是 Speedtronic Mark V 控制系統的一部分。系統控制級電源以及機柜風扇由此卡供電。該卡與許多GE品牌的勵磁機和驅動器兼容，可以安裝在各種系統中。FC2000、AC2000、DC2000、ME2000 和 CB2000 系列的驅動器可以使用此板。饋入電路板的電壓可在 38 至 115 VAC 范圍內安全額定值。

DS200DCFBG1BNC電路板周圍有五個電路。這些電路包括驅動電路、控制級電源電路、電機勵磁電源電路以及交流和直流監控電路。為確保電路不中斷，船上的三個保險絲受到保護。如果需要注意任何保險絲，集成的 LED 和霓虹燈指示燈將提醒用戶。監控電壓電平很重要，可以使用卡上的五個測試點之一來完成。用戶可使用 12 個跳線和 7 個 DIP 開關進行配置。

 >>>>>型號:DS200DCFBG1BNC 電源板 勵磁機和驅動器兼容

【英文介紹】

The DS200DCFBG1BNC is a power supply board manufactured for General Electric's Mark V Series replacement boards and optional boards. The DS200DCFBG1BNC circuit board is part of the Speedtronic Mark V control system. The card supplies power to the system control power supply and the fan of the cabinet. The card is compatible with many GE branded exciters and drives and can be installed in a variety of systems. Drives in the FC2000, AC2000, DC2000, ME2000, and CB2000 series can use this board. The voltage fed into the board can be rated safely in the range of 38 to 115 VAC.

There are five circuits around the DS200DCFBG1BNC circuit board. These circuits include drive circuits, control level power supply circuits, motor excitation power supply circuits, and AC and DC monitoring circuits. To ensure that the circuit is not interrupted, the three fuses on the ship are protected. If any fuses need attention, integrated LED and neon indicators will alert the user. Monitoring voltage levels is important and can be done using one of the five test points on the card. The user can configure with 12 jumpers and 7 DIP switches.
