【功能描述】

IS215ACLEH1B型號是EX2100e系列的一部分，作為應用控制層模塊，通常是基于微處理器的控制器。該板的主要用途是通過通信網絡（如ISBus和以太網）執行多種不同的任務。安裝電路板后，它將占據EX2100勵磁板機架或創新系列驅動器中的兩個半插槽。ACLE板也將位于控制柜內。有許多不同的軟件功能，包括但不限于以下內容：

I/O點和內部布爾強制

創新系列變頻器的應用控制

非易失性閃存

在線應用程序配置加載

控制塊

IS215ACLEH1B板使用以太網連接，該連接使用由主板上的BIOS功能初始化的IRQ 5。ACLE板上的以太網連接是位于ACL板前面板的10baseT或RJ45插孔。作為基于微處理器的控制，該板具有外圍組件互連（PCI）控制器，該控制器將管理不同的輸入和輸出、與PCI總線之間的配置傳輸以及管理各種存儲器功能。

IS215ACLEH1B型號還具有一個128 KB的L2緩存，該緩存與PCI控制器一起使用并由其控制，該緩存設置為152 NC緩存行，該行將填充L1和L2緩存之間的行。ACLE板的另一個特點是閃存設備，該存儲設備位于目標接口的本地總線側，稱為設備1，該設備只能以字節模式訪問。

 >>>>>型號: IS215ACLEH1B 應用程序控制層模塊  通過通信網絡

【英文介紹】

The IS215ACLEH1B model is part of the EX2100e family as an application control layer module, usually a microprocessor-based controller. The main purpose of the board is to perform a variety of different tasks over communication networks such as ISBus and Ethernet. When the board is installed, it will occupy two and a half slots in the EX2100 exciter frame or Innovation series driver. ACLE board will also be located in the control cabinet. There are many different software features, including but not limited to the following:

I/O points and internal Boolean coercion

Application control of innovative series inverter

Non-volatile flash memory

Online application configuration loading

Control block

The IS215ACLEH1B board uses an Ethernet connection that uses IRQ 5 initialized by the BIOS function on the motherboard. The Ethernet connection on the ACLE board is a 10baseT or RJ45 jack located on the front panel of the ACL board. As a microprocessor-based control, the board has a Peripheral Component Interconnection (PCI) controller that will manage different inputs and outputs, configuration transfers to and from the PCI bus, and manage various memory functions.

The IS215ACLEH1B model also has a 128 KB L2 cache that is used with and controlled by the PCI controller, which is set to 152 NC cache rows that will fill the rows between the L1 and L2 caches. Another feature of the ACLE board is a flash device, a storage device located on the local bus side of the target interface called Device 1, which can only be accessed in byte mode.
