【功能描述】

IS215VPROH1BD是為Mark VI系統制造的模塊。Mark VI是Speedtronic系列的燃氣輪機/蒸汽輪機管理系統，由GE開發了30多年，專注于創建可靠和高效的系統。

該IS215VPROH1BD用作緊急渦輪機保護模塊。該IS215VPROH1BD提供速度差檢測和備份同步檢查保護。該板接受熱電偶和模擬輸入。該模塊有兩個電路板堆疊在一起。頂板是一塊IS200VPRW板，通過螺紋固定在支架上的四個螺釘連接安裝到下板上。該板由集成電路、變壓器、多個晶體管以及電阻器、電容器和二極管組成。電容器包括由聚酯乙烯基制成的電容器。電阻器有時由碳復合材料制成。該板具有多個電感線圈和許多連接器，包括插頭。右前側有一個散熱器。

IS215VPROH1BD的底板有兩個背板。它具有電容器和電阻器以及多個集成電路。這包括振蕩芯片。頂板的支架放置在板的邊緣附近。

IS215VPROH1BD通過TREG板控制脫扣螺線管?？刂破髦械膽?yīng)用軟件用于啟動這些脫扣螺線管的測試。這些也可以手動跳閘。

IS215VPROH1BD由面板構成。面板具有LED指示燈、電源開關、電纜連接器和以太網連接器。該面板使用螺釘連接到電路板。有關此模塊的更多信息，請參閱原始設備制造商的出版物。

>>>>>型號: IS215VPROH1BD 緊急渦輪機保護模塊 接受熱電偶和模擬輸入

【英文介紹】

When were the IS215VCMIH2C and Mark VI control systems first released?

The Mark VI was one of the last Speedtronic series to be released by GE. From the late 1960s (MKI) to the 1990s (MKVI and MKVIe), this series of gas turbine/steam turbine management systems was developed in many iterations with the main goal of improving the efficiency of turbine systems through reliable management, good design and the best emerging technologies. The IS215VCMIH2C was released by GE Energy and GE Industrial Solutions during the production of the Mark VI control system.

Product description

The IS215VCMIH2C is designed as a VME communication card in the GE Mark VI turbine control system and is essential for the correct functioning of the entire system. The VCMI VME communication board allows the input/output (I/O) card to communicate with other I/O cards mounted on the VME backplane, expansion rack mounted I/O cards, I/O backup protection module, triple redundancy control module, and main processor module.

The IS215VCMIH2C card is also broadly referred to as the VME bus master controller. The PCB connects the communication between the I/O board and the controller. It also acts as a communication interface for the System Control Network (IONet).

The IS215VCMIH2C has four built-in port connections placed on its front panel. These include an RS-232C serial port, Type D plug connectors, and three IONet 10Base2 Ethernet ports. Each IONet connector is associated with three LED indicators labeled TX/RX/CD. The board has additional LED indicators labeled Status, Failure, Run, and 1, 2, 4, and 8. The former is located above the reset switch (button), while the latter is located directly below the serial port.
