>>>>>型號: IS220PPROS1B 配電系統反饋模型 電源板兼容
【功能描述】
IS220PPROS1B板是通用電氣為Mark VIe系統制作的配電系統反饋模型。該型號用于調節電路板反饋信號，還可以為連接的控制器提供以太網接口。此電池組的反饋安排為即插即用，它將使用它插入的電子ID來確定所連接配電型號的功率。來自配電模型的信息將繼續用于占用IONet輸出，以提供來自連接的正確反饋。
雖然IS220PPROS1B包與JPDC、JPDS、JPDM和JPDG電源板兼容，但它僅與來自JPDB、JPDF和JPDE板的反饋信號兼容。通常，此PPDA包安裝在以下板之一上;JPDM、JPDC或JPDS。通過使用50針帶狀電纜跳線通過引腳一對一連接器的接線，該電池組可以連接到更多電路板。
自動重新配置是IS220PPROS1B包的主要操作組件之一。自動重新配置功能允許輕松更換I/O包，因為更換包無需重新配置。請注意，在進行自動重新配置時，用戶在重新配置完成之前將無法重新啟動。在重新配置過程中，無法進行其他需要進行的下載。
>>>>>型號: IS220PPROS1B 配電系統反饋模型 電源板兼容
【英文介紹】
The IS220PPROH1A is an I/O module for turbines. It is designed to provide a direct interface to specific turbine site equipment. This setup eliminates or reduces much of the instrumentation previously required to connect to field equipment, and also improves operational reliability and reduces long-term maintenance. The IS220PPROH1A is usually used in conjunction with the TREAH_A terminal board for emergency trip applications in aircraft modification turbines. The assembly can be connected to fence or box terminals. The IS220PPROH1A has field wiring limits for voltage detection, limiting cable length to 1,000 feet of 18 AWG wiring. Note that the IS220PPROH1A cannot be automatically reconfigured when swapping BPPB P-Pack with BPPC P-Pack.
The IS220PPROH1A has a built-in front panel marked with the component ID number and several LED indicators. They are placed in pairs on the front panel. The first pair is labeled PWR/ATTN, the second pair is labeled LINK/TxRx and ENET 1, and the third pair is labeled LINK/TxRx and ENET2. The last component is located at the bottom of the panel; This is labeled as an IR port.
The IS220PPROH1A accepts three speed signals. This includes deceleration, acceleration and speeding. The component also has hardware to enable overspeed. The kit monitors the status and operation of the selected trip plate through a comprehensive set of feedback signals. The suite supports TMR and simplex backup protection.
