IC698CPE030 | 可編程自動化控制器 (PAC)
<P> 該IC698CPE030是可編程自動化控制器 (PAC) 的 PACSystem RX7i 中最先進的中央處理器 (CPU) 之一。該
CPU 旨在滿足行業的現代自動化、連接和集成要求。它以前由 GE 智能平臺 (GE IP) 制造，但隨著最近被艾默生自動化收購，PACSystem RX7i
現在是后者的一部分。</P>
<P> IC698CPE030處理器安裝了計算機級微處理器，即 600MHz Pentium-M
微處理器，具有 64 MB 用戶內存和 64 MB 用戶閃存。它的布爾執行速度為每 1000 個布爾觸點/線圈 0.069 毫秒。該 CPU 最多可容納 32
K 位的離散 I/O 和 32 K 字的模擬 I/O，最多可以下載 512 個程序塊到該 CPU，其中每個程序塊最多可以有 128 KB
內存。</P>
<P> 該IC698CPE030還具有兩 (2)
個以太網通信端口，能夠自動感應網絡傳輸速度，并可配置為半雙工和全雙工操作模式。內置的 Web 服務器和文件傳輸協議 (FTP)
功能可通過這些以太網端口訪問，允許用戶遠程監控和配置處理器。除了內置以太網端口外，</P>
<P> 該 CPU 還具有一 (1)
個 RS232 端口;一 (1) 個 RS485 端口和一 (1) 個工作站管理器端口。這些通信接口支持SRTP、Modbus
TCP服務器和客戶端、用于基于以太網的通信的以太網全局?jǐn)?shù)據(EGD)和用于串行通信的Modbus RTU
Slave、SNP、串行I/O。</P>
<P> The IC698CPE030 is one of the most
advanced central processing units (cpus) in the Programmable Automation
Controller (PAC) PACSystem RX7i. The CPU is designed to meet the modern
automation, connectivity and integration requirements of the industry. It was
previously manufactured by GE Intelligent Platforms (GE IP), but with its recent
acquisition by Emerson Automation, PACSystem RX7i is now part of the
latter.</P>
<P> The IC698CPE030 processor is equipped with a
computer-grade microprocessor, namely a 600MHz Pentium-M microprocessor, with 64
MB of user memory and 64 MB of user flash memory. It has a Boolean execution
speed of 0.069 milliseconds per 1000 Boolean contacts/coils. The CPU can hold up
to 32K bits of discrete I/O and 32K words of analog I/O, and up to 512 blocks
can be downloaded to the CPU, where each block can have up to 128 KB of
memory.</P>
<P> The IC698CPE030 also features two (2) Ethernet
communication ports that automatically sense network transmission speeds and can
be configured for both half-duplex and full-duplex operating modes. The built-in
Web server and File Transfer Protocol (FTP) capabilities are accessible through
these Ethernet ports, allowing users to remotely monitor and configure the
processor. In addition to a built-in Ethernet port,</P>
<P> The
CPU also has one (1) RS232 port; One (1) RS485 port and one (1) workstation
manager port. These communication interfaces support SRTP, Modbus TCP server and
client, Ethernet Global Data (EGD) for Ethernet-based communication, and Modbus
RTU Slave, SNP, and serial I/O for serial communication.</P>
