IS220PDIAH1A  |  Mark V系列  | 通信模塊

　型號：IS220PDIAH1A

　　觸點潤濕輸出 :32 伏直流電

　　功能縮略語/縮寫: PDIA的

　　最小電壓 ：27.4 伏直流電

　　型號類型 ：離散 I/O 包

　　零件編號：IS220PDIAH1A

　　與Mark V系列中的其他型號相比，IS220PDIAH1A不一定有特定的面板，因為它是一個!/0包。在設備的正面有七個指示燈，在包裝的右側有三個組的電源指示燈和兩個鏈路指示燈，一個表示ENet1，另一個表示ENet2。在這三個指示器下面，有一個以太網端口，用于將模型連接到以太網,以方便以太網通信。

　　IS220PDIAH1A包具有位置標準，其中兩個是UL 600790 Ed。5和UL60079-15版。3用于1C|級2區組。該信息可在GEH-6725 Mark V控制設備Hazloc手冊中找到，該手冊位于手冊選項卡下。

　　Model: IS220PDIAH1A

　　Contact wetting output :32 volts DC

　　Functional acronym/abbreviation: PDIA

　　Minimum voltage: 27.4 volts DC

　　Model Type: Discrete I/O packet

　　Part number: IS220PDIAH1A

　　Compared to other models in the Mark V series, the IS220PDIAH1A doesn't necessarily have a specific panel, just because it is one! The /0 packet. There are seven indicators on the front of the device, and on the right side of the package there are three groups of power indicators and two link indicators, one for ENet1 and the other for ENet2. Underneath these three indicators, there is an Ethernet port for connecting the model to Ethernet to facilitate Ethernet communication.

　　The IS220PDIAH1A package has location standards, two of which are UL 600790 Ed. 5 and UL60079-15 editions. 3 For 1C| level 2 area group. This information can be found in the GEH-6725 Mark V Control Device Hazloc manual, which is located under the Manual TAB.
