IS220UCSAH1A  |控制器模塊  |  用于連接通信

　零件編號 IS220UCSAH1A

　　功能首字母縮略詞 UCSA

　　功能描述 PAMC 聲學監測器(處理器)

　　說明書 GEH-6725R型

　　PCB涂層 三防漆

　　應用 Mark VIe、Mark VIes、EX2100e、LS2100e

　　功能修訂版 1 一個

　　產品類型 Mark VIe 控制器

　　該IS220UCSAH1A是通用電氣為Mark VI系統創建的處理器/控制器。Mark VI平臺設計用于管理燃?xì)廨啓C(jī)或蒸汽輪機，由GE作為Speedtronic系列的一部分發布。它具有 HMI(人機界面)和專為運行重型渦輪機而設計的軟件，例如 CIMPLICITY 圖形界面。

　　IS220UCSAH1A 被構建為一個單一的盒裝組件，帶有一個前面板，用于連接通信，后邊緣有兩個螺釘支架，三個側面有格柵開口，允許空氣流動。該控制器設計用于在機柜內安裝底座。最多可將三個組件彼此相鄰安裝，以實現緊湊的布置，可輕松為三重冗余系統提供服務。

　　該IS220UCSAH1A適用于 QNX 操作系統。它有一個飛思卡爾8349,667 MHz處理器。該板使用額定電壓為 18-36 V 直流、12 瓦的電源。該板可在 0 至 65 攝氏度的溫度下使用，即使在最高額定溫度下也不需要風扇進行冷卻。該板可用于 NFPA 1 類 2 類應用。

　　Part number IS220UCSAH1A

　　Functional acronym UCSA

　　Function Description PAMC Acoustic Monitor (Processor)

　　Instruction Manual GEH-6725R

　　PCB coating three anti-paint

　　Apply Mark VIe, Mark VIes, EX2100e, and LS2100e

　　Feature revision 1 One

　　Product Type Mark VIe Controller

　　The IS220UCSAH1A is a processor/controller created by General Electric for the Mark VI system. The Mark VI platform is designed to manage gas or steam turbines and is released by GE as part of the Speedtronic family. It has an HMI (Human machine interface) and software designed for running heavy duty turbines, such as the CIMPLICITY graphical interface.

　　The IS220UCSAH1A is built as a single boxed assembly with a front panel for connecting communications, two screw brackets on the back edge, and grille openings on three sides to allow air flow. The controller is designed for mounting a base in a cabinet. Up to three components can be installed next to each other for a compact arrangement that easily serves triple-redundant systems.

　　The IS220UCSAH1A is suitable for the QNX operating system. It has a Freescale 8349,667 MHz processor. The board uses a rated voltage of 18-36 V DC, 12 watts of power supply. The board can be used at temperatures from 0 to 65 degrees Celsius and does not require a fan for cooling even at the highest rated temperature. The board can be used for NFPA Class 1 Class 2 applications.
