IS220PTURH1B | I/O 輸入輸出模塊 | 以太網端口
模型:IS220PTURH1B
存儲深度(每通道):512k采樣點/ch
觸發方式:手動觸發、內部觸發、外部觸發
工作模式在線、離線(黑匣子)
信號輸入:v/q或v/icp
通信端口:rj45以太網端口
產品描述
IS220PDIAH1B是GE Mark VIe I/O封裝，可與各種GE端子板結合使用。這是由AX Control提供的幾個I/O包/板組合之一。其中許多設備已被原始設備制造商置于遺留狀態，制造商可能不再提供這些設備。axcontrol盡最大努力保持這些產品的現有庫存，以更好地服務于我們的客戶。
IS220PDIAH1B被批準用于危險場所。PDIA I/O可以與許多不同的端板配對，包括IS200STCIH1A和2A, IS200STCIH8A, Is200TBCIH2C或H4C, IS400TBCIH2C, IS400STCIH1A或2A或IS400STCIH8A。這些通常是配電盤，是Mark VIe Speedtronic系統的一部分。
IS220PDIAH1B I/O封裝的額定電壓為24.0 VDC，最大額定值為28.6。觸點輸入最大額定電壓為32vdc。該裝置通過UL認證，可用于非危險和危險場所。所有不同等級和地區的UL標志請參考相關文檔。IS220PDIAH1B設計用于-30至+65攝氏度(環境溫度)之間的溫度。
Model: IS220PTURH1B
Storage depth (per channel) : 512k sample point /ch
Trigger mode: manual trigger, internal trigger, and external trigger
Working mode Online, Offline (Black box)
Signal input: v/q or v/icp
Communication port: rj45 Ethernet port
Product description
The IS220PDIAH1B is a GE Mark VIe I/O package that is combined with various GE terminal boards. This is one of several I/O package/board combinations offered by AX Control. Many of these devices have been placed in a legacy state by Oems and may no longer be offered by manufacturers. AX Control makes its best efforts to maintain existing inventory of these products to better serve our customers.
The IS220PDIAH1B is approved for use in hazardous sites. The PDIA I/O can be paired with a number of different end boards, including IS200STCIH1A and 2A, IS200STCIH8A, Is200TBCIH2C or H4C, IS400TBCIH2C, IS400STCIH1A or 2A or IS400STCIH8A. These are usually the switchboards that are part of the Mark VIe Speedtronic system.
The IS220PDIAH1B I/O package has a rated voltage of 24.0 VDC and a maximum rating of 28.6. The maximum rated voltage of the contact input is 32 VDC. The unit is UL certified for use in both non-hazardous and hazardous sites. Please refer to the documentation for all UL marks of different grades and regions. The IS220PDIAH1B is designed for temperatures between -30 and +65 degrees Celsius (ambient temperature).
