IS200TRPGH1BDE  |  電位器  |   能夠精確測量渦輪轉速

　　IS200TRPGH1BDE由通用電氣制造，作為其Markl和Markll系列的一部分。

　　IS200TRPGH1BDE有8個大型可變電阻，也稱為電位器。 這些可變電阻器通過工人在其表面轉動一個小螺絲來限制能量。

　　IS200TRPGH1BDE也有大約50種不同顏色的電阻，具有多個顏色帶。 這些設備具有可限制的預定能量。 如果有人想知道每個手電筒有多少人能看到

　　能量，每個色帶對應一個色碼做一個方程來計算。

　　IS200TRPGH1BDE有6個紅色方形電容器，3個黃色電容器和2個橙色圓形電容器。 電容器將多余的能量?jī)?chǔ)存在它們產生的電場中。

　　IS200TRPGH1BDE三個銀色圓形晶體管和十個黑色小晶體管。 大管被用來放大和改變電子信號或電能。 IC3600SOTH1有近70個金屬引腳，也稱為公端子

　　這些公端子用于將IS200TRPGH1BDE連接到系統的其余部分。

　　輸入輸出配置

　　IS200TRPGH1BDE端子板具有全面的輸入輸出范圍，確保高效的操作和控制:

　　客戶輸入終端:這些輸入由兩個24點可插拔的屏障終端提供便利，為客戶特定的輸入提供有組織和可訪問的接口

　　9個無源脈沖速率裝置:這些裝置分布在X//Z段，每段3個，具有負儀表感應齒輪，從而能夠精確測量渦輪轉速。

　　用于信號震蕩的跳線模塊:跳線模塊在使一組三速輸入能夠震蕩到所有三個PPROI/0數據包，優化信號分配以實現統一功能方面發揮關鍵作用。

　　125 VDC TMR投票輸出觸點:這些標有H2A和H4A的輸出觸點是系統跳閘激活的關鍵部件，確保在緊急情況下采取故障安全措施

　　電壓檢測電路:IS200TRPGH1BDE從24到125 VDC的四個電路專門用于監測脫扣串，通過連續監測電壓水平來提高系統的安全性和可靠性。

　　子板連接器:包含子板連接器允許可選的功能擴展，為附加或增強的功能提供可擴展性和自定義可能性。

　　Product translator:

　　The IS200TRPGH1BDE is manufactured by General Electric as part of its Markl and Markll series.

　　The IS200TRPGH1BDE has eight large variable resistors, also known as potentiometers. These variable resistors limit energy by a worker turning a small screw on their surface.

　　The IS200TRPGH1BDE also has about 50 different colored resistors with multiple color bands. These devices have a predetermined amount of energy that can be limited. If anyone wants to figure out how many people can see each flashlight

　　Energy, each color band corresponds to a color code to do an equation to calculate.

　　The IS200TRPGH1BDE has six red square capacitors, three yellow capacitors and two orange round capacitors. Capacitors store excess energy in the electric fields they generate.

　　IS200TRPGH1BDE Three circular silver transistors and ten small black transistors. The bulk tube is used to amplify and alter electronic signals or electrical energy. The IC3600SOTH1 has nearly seventy metal pins, also known as male terminals

　　These male terminals are used to connect the IS200TRPGH1BDE to the rest of the system.

　　Input and output configuration

　　The IS200TRPGH1BDE terminal board has a comprehensive input and output range to ensure efficient operation and control:

　　Customer input terminals: These inputs are facilitated by two 24-point pluggable barrier terminals, providing an organized and accessible interface for customer-specific inputs

　　Nine passive pulse rate devices: These devices are distributed in the X//Z section, three in each section, with negative meter induction gears, thus enabling accurate measurement of turbine speed.

　　Jumper blocks for signal flapping: Jumper blocks play a key role in enabling a set of three-speed inputs to flap to all three PPROI/0 packets, optimizing signal distribution for uniform functionality.

　　125 VDC TMR Voting Output contacts: These output contacts, labeled H2A and H4A, are key components for system trip activation, ensuring fail-safe measures in the event of an emergency

　　Voltage Detection circuits :IS200TRPGH1BDE Four circuits from 24 to 125 VDC are dedicated to monitoring trip strings to improve system safety and reliability by continuously monitoring voltage levels.

　　Child board connectors: The inclusion of child board connectors allows for optional feature extensions, providing scalability and customization possibilities for additional or enhanced features.
