IC693CPU352RR  |  單插槽CPU模塊  |  配置和編程軟件支持 CPU352

　　型號：IC693CPU352RR

　　系列 ：90-30系列

　　產品類型 :CPU模塊

　　微處理器: 80386EX

　　電壓輸入: 5 伏直流電

　　電流消耗 :670毫安

　　時鐘速度 :25兆赫茲

　　定時器和計數器: 2000>

　　寄存器存儲器 :9999字

　　以太網端口數 ;不適用

　　內存存儲類型 ;RAM和閃存

　　典型掃描速率 ;每 1K 邏輯 0.22 毫秒(布爾觸點)

　　串行端口'; RS-485(通過電源

　　電源要求: 670 毫安，+5 VDC 電源供電

　　處理器類型; 80386EX

　　用戶記憶; 240K 字節

　　CPU類型 ; 單插槽CPU模塊

　　IC693CPU352RR是GE Automation and Controls為90/30系列PLC系統制造的單插槽CPU模塊。 每個系統的底板總數為 8 個，其中包括一個用于 CPU 的底板，以及 7 個遠程和擴展。電源的負載要求為890mA，采用+5V直流電源供電。處理器類型是 80386EX，IC693CPU352RR 處理速度為 25Mhz。系統的最佳工作溫度在 0 攝氏度到 60 攝氏度(32 華氏度到 140 華氏度)之間。該規范也稱為環境溫度。對于每 1K 邏輯(即布爾觸點)，典型的掃描速率為 0.22 毫秒。

　　有 2000 多個定時器/計數器，并且還有移位寄存器。內置三個串行端口，支持RTU從站和SNP或SNPX從站，SNP或SNPX主站或從站，以及串行輸入/輸出(在端口1和端口2上)。通信支持LAN(支持多點)、以太網、Profibus、FIP、GBC、GCM+選項模塊。閃存和 RAM 是可用的存儲內存類型。Logicmaster 配置和編程軟件支持 CPU352。

　　Model: IC693CPU352RR

　　Series: 90-30 series

　　Product type :CPU module

　　Microprocessor: 80386EX

　　Voltage input: 5 volts DC

　　Current consumption :670 MA

　　Clock speed :25 MHZ

　　Timers and counters: 2000>

　　Register memory :9999 words

　　Number of Ethernet ports; inapplicability

　　Memory storage type; RAM and Flash

　　Typical scanning rate; 0.22 milliseconds per 1K logic (Boolean contacts)

　　Serial port '; RS-485 (via power supply

　　Power requirements: 670 MA, +5 VDC power supply

　　Processor type; 80386EX

　　User memory; 240K bytes

　　CPU type; Single-socket CPU module

　　The IC693CPU352RR is a single socket CPU module manufactured by GE Automation and Controls for the 90/30 series PLC system. The total number of backboards per system is eight, including one for the CPU, and seven for remote and extension. The load requirement of the power supply is 890mA, and the power supply is +5V DC. The processor type is 80386EX, and the IC693CPU352RR has a processing speed of 25Mhz. The optimal operating temperature of the system is between 0 ° C and 60 ° C (32 ° F to 140 ° F). This specification is also called ambient temperature. For every 1K of logic (i.e., Boolean contacts), the typical scan rate is 0.22 milliseconds.

　　There are more than 2000 timers/counters, and there are shift registers. Three built-in serial ports support RTU slave and SNP or SNPX slave, SNP or SNPX master or slave, and serial input/output (on ports 1 and 2). Communication supports LAN (multi-point support), Ethernet, Profibus, FIP, GBC, GCM+ option modules. Flash and RAM are the types of storage memory available. The Logicmaster configuration and programming software supports CPU352.
