DS200TCQCG1AJD | 輸入/輸出網格叉模塊 | 369B1860G0030

　　型號:DS200TCQCG1AJD

　　分類:輸入/輸出網格叉模塊

　　保證:一年保修

　　產品描述

　　GE RST溢出板DS200TCQCG1AHD配備了24個跳線和3個40針連接器。 它還具有三個34針連接器和一個16針連接器。 分配給16針連接器的ID是JC。 分配給40針連接器的id是JFF, JE和6PL。 GE RST溢流板上的24條跳線在GE RST溢流板的配置中起著重要的作用

　　DS200TCQCG1AHD董事會。 跳線有兩個位置，安裝人員可以在其中設置跳線。 根據不同的選擇，委員會將以不同的方式處理這些信息。 跳線定義為3針跳線。 也就是說，跳線可以覆蓋引腳1和2或引腳2和3。 跳線在它所覆蓋的兩個引腳之間進行電接觸。 有些跳線不是由安裝人員設置的，而是工廠在產品測試時使用的。 在這種情況下，一個位置由制造商使用，另一個位置在正常操作期間使用。

　　DS200TCQCG1AJD跳線是在電路板安裝到驅動程序之前設置的，并且需要安裝手冊中提供的信息來了解可用的配置選項。 通常，安裝現場的工程師和管理人員將與安裝人員進行協商。 通過這種通信，安裝人員知道工程師想要如何設置跳線。

　　PCB連接器包括:

　　點刺式連接器

　　插頭

　　直角連接器

　　DS200TCQCG1AJD | Input/Output grid fork module | 369B1860G0030

　　Model :DS200TCQCG1AJD

　　Category: Input/Output grid fork modules

　　Guarantee: One year warranty

　　Product description

　　The GE RST overflow board DS200TCQCG1AHD is equipped with 24 jumpers and 3 40-pin connectors. It also features three 34-pin connectors and one 16-pin connector. The ID assigned to the 16-pin connector is JC. The ids assigned to 40-pin connectors are JFF, JE, and 6PL. The 24 jumpers on the GE RST overflow plate play an important role in the configuration of the GE RST overflow plate

　　DS200TCQCG1AHD Board of Directors. The jumper has two locations where the installer can set the jumper. Depending on the options, the Committee will handle this information in different ways. The jumper is defined as a 3-pin jumper. That is, the jumper can cover pins 1 and 2 or pins 2 and 3. The jumper makes electrical contact between the two pins it covers. Some jumpers are not set by the installer, but are used by the factory during product testing. In this case, one location is used by the manufacturer and the other is used during normal operation.

　　The DS200TCQCG1AJD jumper is set before the board is installed to the driver, and the information provided in the installation manual is required to understand the configuration options available. Typically, engineers and managers at the installation site will consult with the installer. Through this communication, the installer knows how the engineer wants to set up the jumper.

　　PCB connectors include:

　　Point connector

　　plug

　　Right Angle connector
