IS215ACLEH1AB  | EX2100 勵磁控制器 | DS215TCQAG1BZZ01A

　　型號：IS215ACLEH1AB

　　系列 EX2100 勵磁控制器

　　組和功能修訂 H1B型

　　潛在添加組件 舞會

　　硬件特性 LED、CPU 和 PCI 控制器

　　軟件特點 基本輸入/輸出系統

　　緩存級別 級別 2,128 KB

　　重量 1磅 4盎司

　　運輸尺寸 18x12x12英寸

　　原產國 美國 (USA)

　　產品描述

　　IS215ACLEH1B 型號是 EX2100e 系列的一部分，作為應用控制層模塊，通常是基于微處理器的控制器。該板的主要用途是通過通信網絡(如 ISBus 和以太網)執行多種不同的職責。安裝電路板后，它將占據 EX2100 激勵板機架或創新系列驅動器中的兩個半插槽。ACLE板也將位于控制柜內。有許多不同的軟件功能，包括但不限于以下內容：

　　I/O 點和內部布爾強制

　　創新系列變頻器的應用控制

　　非易失性閃存

　　在線應用程序配置加載

　　控制塊

　　IS215ACLEH1B板使用以太網連接，該連接使用由板上的 BIOS 功能初始化的 IRQ 5。ACLE 板上的以太網連接是位于 ACL 板前面板上的 10baseT 或 RJ45 插孔。作為基于微處理器的控制，該板具有外設組件互連 (PCI) 控制器，用于管理不同的輸入和輸出、與 PCI 總線之間的配置傳輸以及管理各種存儲器功能。

　　IS215ACLEH1B型號還具有一個 128 KB 的 L2 緩存，該緩存與 PCI 控制器一起使用并由 PCI 控制器控制，該緩存設置為 152 NC 緩存

　　Model: IS215ACLEH1AB

　　Series EX2100 excitation controller

　　Group and function revision H1B type

　　Potential added components for PROM

　　Hardware Features LED, CPU and PCI controller

　　Software features Basic input/output system

　　Cache Level Level 2,128 KB

　　Weighs 1 pound, 4 ounces

　　Shipping size 18x12x12 inches

　　Country of origin United States (USA)

　　Product description

　　The IS215ACLEH1B model is part of the EX2100e family as an application control layer module, usually a microprocessor-based controller. The main purpose of the board is to perform a variety of different duties over communication networks such as ISBus and Ethernet. When the board is installed, it will occupy two and a half slots in the EX2100 driver frame or Innovation series drivers. ACLE board will also be located in the control cabinet. There are many different software features, including but not limited to the following:

　　I/O points and internal Boolean coercion

　　Application control of innovative series inverter

　　Non-volatile flash memory

　　Online application configuration loading

　　Control block

　　The IS215ACLEH1B board uses an Ethernet connection that uses the IRQ 5 initialized by the BIOS function on the board. The Ethernet connection on the ACLE board is a 10baseT or RJ45 jack located on the front panel of the ACL board. As a microprocessor-based control, the board has a Peripheral component Interconnect (PCI) controller for managing different inputs and outputs, configuration transfers to and from the PCI bus, and managing various memory functions.

　　The IS215ACLEH1B model also has a 128 KB L2 cache that is used with and controlled by the PCI controller, which is set to 152 NC cache
