【功能描述】
IS200TVIBH2BBB是一種稱為端子板的設備。該IS200TVIBH2BBB是通用電氣或通用電氣制造的Mark VI系列的眾多組件之一。Mark VI和Mark系列中的其他系列已被用于管理燃?xì)廨啓C(jī)和蒸汽輪機的所有過程1969年，當Mark I首次推出時。
IS200TVIBH2BBB是一個長方形的長印刷電路板。三（3）個長綠色接線端子位于IS200TVIBH2BBB的左邊緣。每個接線端子都包含多個端子，這些端子很小，由銀色金屬制成。緊挨著IS200TVIBH2BBB下半部分接線端子的是一組粉紅色電容器。這些電容器又小又圓。這些電容器已訂購成兩（2）排，每排至少二十（20）個電容器。三（3）個額外的粉紅色電容器位于IS200TVIBH2BBB下邊緣的中心附近。在接線端子旁邊的IS200TVIBH2BBB的上半部分是一系列跳線引腳。這些跳線引腳排成兩（2）排，每排十二（12）組。每組包含三（3）個小金屬跳線引腳。IS200TVIBH2BBB上有兩個電位器，有時交替稱為可變電阻器。其中一（1）個電位器放置在中心的IS200TVIBH2BBB頂部附近，另一個位于IS200TVIBH2BBB底部的正對面。電位器是實心的，顏色為淺灰色。
>>>>>型號:IS200TVIBH2BBB 端子板的設備 為可變電阻器
【英文介紹】
The IS200TVBAH2ACC board is a group isolated contact input manufactured by General Electric as part of the Mark VIe system. The main feature of the board is to accept up to 24 dry contact inputs, which are connected to two barrier type terminals. Noise suppression circuit is mainly used to prevent high frequency noise and surge. The board can be used for triple modular redundancy (TMR), dual and simplex applications.
Because the board can be used for a variety of applications, multiple connections with the IS200TVBAH2ACC board can be made depending on the application used. When used in TMR systems, TBCI boards will be connected to I/O processors using JS1, JT1, and JR1 connectors. When used in complex systems, the I/O processor will be connected to a single JR1 connector. Since this model is used in the Mark VIe system, the I/O package will be connected to the TBCI and then to the side mount bracket.
The IS200TVBAH2ACC board can perform many diagnostic tests. For example, when the input of the board does not match the voting values of the three boards used in the TMR system, a fault is generated to ensure that the fault is fixed. Note that there are no hardware Settings or jumpers on the board.
