>>>>>型號:IS215UCVEM10A 精密電路板組裝模塊 印刷電路板

【功能描述】

該IS215UCVEM10A是為Mark VIe系列風力渦輪機控制自動化組件生產的精密電路板組裝模塊。該P(yáng)CB在其特殊組裝版本中是獨一無二的，如其個性化產品編號開頭的IS215系列標簽所示。該模塊組件由IS215UCCAH3計算引擎、128 MB閃存、128 MB額外DRAM和IS200 EPMC板組成。與AX Control提供的絕大多數產品一樣，此控制器計算引擎模塊組件在購買時享有三年保修，并可額外進行維修。大多數印刷電路板組件的維修標準交貨時間為一到兩周。

硬件提示和規格

如前所述，IS215UCCAH3實際上作為幾個組件的系列存在。在確定整個IS215UCCAH3組件的重要硬件規格時，了解Controller Compute Engine IS215UCCAH3組件的機制和硬件規格至關重要。該IS215UCCAH3型號是保形涂層印刷電路板，也可用作更大的Mark VIe系列自動驅動器組件的控制器計算引擎。此PCB或印刷電路板是單插槽板，具有65 MHZ英特爾賽揚微處理器和兩個PCI夾層卡站點。該控制器計算引擎組件標配其他重要規格，包括固定在主板面板上的RJ45以太網端口和用于進程限制的看門狗定時器。IS215UCCAH3計算引擎的RJ-45以太網端口的目的是提供與更大驅動器組件的單元數據高速公路（UDH）的連接，以實現通信目的。

IS215UCVEM10A Compute Engine模塊組件中存在的IS200EPMC組件是一個子板，它分擔了IS215UCCAH3的一些微處理負載。該子板以及IS215UCCAH3計算引擎與128 MB閃存和DRAM相結合，大大提高了新創建的IS215UCVEM10A3組裝模塊的整體功能和處理能力。有關支持此組件創建和處理的一些硬件規格的更多信息，可以通過使用詳盡的IS215UCVEM10A部件號細分來發現，如上面手冊選項卡中附IS215UCVEM10A部件號細分中所述。例如，IS215UCVEM10A個性化部件號的M03部分將此模塊組件指定為模塊組件，而不是單個電路板。該產品編號部分也表明了該UCCA組件作為Mark VIe系列第三組成員的地位。對IS215UCCAH3 Compute Engine進行額外的產品部件細分可能會有所幫助，因?yàn)檫@可以為模塊組件提供其他相關信息，包括其保護性PCB涂層類型。

 >>>>>型號:IS215UCVEM10A 精密電路板組裝模塊 印刷電路板

【英文介紹】

The IS215UCVEH2AE is a component of the General Electric Mark VI Speedtronic control system. The board is used as a VME control card. The VME bracket is the standard Mark VI bracket and can be used as a 13 - or 21-slot rack.

IS215UCVEH2AE is a rectangular board with a front panel. Both the top and bottom of the panel have a set screw to help hold the board in place after mounting it into the rack system. The front panel includes one Ethernet port, two COM ports, and one LAN port. It also has an opening for a sandwich card.

The board itself consists of a vertical pin connector within the board body and a right Angle pin connector along the edge of the board. In addition, the board has multiple integrated circuits, resistors, capacitors, chokes, and other components. In addition, there is a small circuit board mounted at an Angle in the center of the circuit board, and the radiator cap is located more than half of the circuit board.
