>>>>>型號:IS220PDOAH1A 離散輸入模塊 具有特定的面板

【功能描述】

標記為離散I/O包的IS220PDOAH1A型號也用于Mark VI系列和YDIA離散輸入模塊。PDIA模型可以使用幾種不同的相關端子板，其中包括：

IS200TBCIH4C

IS200STCIH1A

IS200STCIH8A

IS200TBCIH2C

IS200TCIH2A

這些型號都與PDIA配合使用，以批準在危險場所使用。在危險環境中使用時，需要特定的認證。認證ULE207685用于非危險、I類2區IIC組和I類2類組A、B、C和D位置。在ATEX Zone 2 Group IIC場所使用時需要特定的認證，該認證為UL DEMKO 12 ATEX 1114875X。

與Mark VI系列中的其他型號相比，IS220PDOAH1A不一定具有特定的面板，因?yàn)樗且粋€(gè)I/O包。在設備的正面，有七個指示燈，在電池組的右側，每組三個，電源指示燈和鏈路指示燈兩個，一個指示ENet1，另一個表示ENet2。在這三個指示燈下方，有一個以太網端口，用于將模型連接到以太網，以便于以太網通信。

IS220PDOAH1A包具有位置標準，其中兩個是UL 600790第5版和UL 60079-15第3版，用于I類2區IIC組。此信息可以在GEH-6725 Mark VI控制設備Hazloc手冊中找到，該手冊位于上面的手冊選項卡下。

>>>>>型號:IS220PDOAH1A 離散輸入模塊 具有特定的面板

【英文介紹】

The IS220PAICH1A model is described as an analog I/O package that has been approved for use in hazardous and non-hazardous locations. On the front side of the model, there are four indicators. There is also a port on the bottom, which is described as an I/O port. The PAIC battery pack can use a variety of voltages, the minimum voltage of the PAIC battery pack is 27.4 volts DC.

Because the IS220PAICH1A kit is capable of being used in many locations, various certifications have been obtained, some of which are Hazardous Sites, Zone 1 Group 2 Iics, Zone 1 Group 2 A, B, C, D and ATEX Zone 2, IIC Group and non-hazardous Sites. The following certifications are used in locations, UL E207685 and UL DEMKO 12 ATEX 1114875X, please note that UL E207685 certifications are used in many locations.

The IS220PAICH1A unit can be used in three models, namely the IS200STAIH1A and IS200STAIH2A, and the IS20TBAIH1C model. All of these models are referred to as input/output terminals.

The typical location for a PAIC I/O package will be in one of the two available VME racks, i.e. 13 or 21 slot racks. Note that this device is often used with triple modular redundant architecture systems. The TMR system has a separate control module, I/O network, and main processor card.
