【功能描述】

DS200DCFBG1BGBGB是通用電氣為Mark V板系列制造的電源板。AC2000、CB2000、DC2000、FC2000、ME2000和EX2000系列機器可以將主板安裝在驅動器中。安裝后，此卡可以為驅動器提供控制級電源和機柜風扇電源。額定電壓在38至115 VAC之間，可通過控制電源變壓器直接提供給電路板。電路板的頻率取決于輸入電壓，但范圍為0至500 kHz。

該板具有許多電路，用于為電路板和已安裝的驅動器供電。DS200DCFBG1BGBGB由電機勵磁電源、驅動器、AC/DC監控和控制級電源電路組成。板上的12個跳線和7個DIP開關為用戶提供了可配置的系統選項。保險絲開關診斷使用電路板上的兩個LED和一個霓虹燈指示燈進行。三個保護保險絲可防止電源中斷。可以使用電路板上集成的五個測試點來監控電壓。

應遵循制造商提供的DS200DCFBG1BGBGB和已安裝驅動器的安裝和存儲參數。這些將防止對兩個單元造成任何意外或可預防的損壞。有關接線和安裝電路板的完整指南，請參閱設備的手冊和數據表。最初，該板和Mark V系列的技術支持由制造商通用電氣提供。

>>>>>型號:DS200DCFBG1BGB  電源板 可防止電源中斷

【英文介紹】

DS200CTBAG1ADD GE Mark V terminal board

DS200CTBAG1ADD is a terminal board designed for GE Mark V Speedtronic systems. The Speedtronic family was created by General Electric to control large and small gas and steam turbine systems. MKV can be designed with simplex or TMR/ triple modular redundancy architecture to meet the needs of interconnected turbine systems. The boards are no longer manufactured and distributed by GE, but can be purchased as fully tested and refurbished models through AX Control.

The DS200CTBAG1ADD is a long, narrow circuit board with only a few types of components. It drilled holes in each corner and long side to allow for the installation of hardware and other connections. Two of the holes are surrounded by conductive material. The board is marked with an identification code, including the board ID number and the company logo.

DS200CTBAG1ADD is an analog terminal module. It is usually located in the R5> Inside the kernel. The board has multiple connectors, including two COREBUS connectors (JAI and JAJ). The DS200CTBAG1ADD has two double-stacked terminal blocks located at the edge of a longboard with multiple connectors on each terminal block. There are 5 vertical pin cable connectors, 2 vertical pin connector connectors, and a 9-pin male serial connector.

Other components on the DS200CTBAG1ADD include a resistor network array, relays, transistors, more than two dozen metal oxide varistors (MOV), a dozen jumper switches, and many capacitors and resistors. For more information, see GE's original technical support offering.
