>>>>>型號:DS200DMCBG1AKG 處理器板 表面貼裝復位開關

【功能描述】

DS200DMCBG1AKG技術規格

制造者GE通用電氣

系列EX2000型

零件編號DS200DMCBG1AKG

功能描述IOS DUP處理器板DS200DMCBG1AKG是由值得信賴的工業零售商通用電氣生產的GE IOS處理器板?；ヂ?lián)網上教學手冊材料的相對稀缺性使得它很難區分特定的制造商和系列，但

硬件提示和規格

與許多GE工業系統Fanuc產品一樣，GE IOS DUP處理器板DS200DMCBG1AKG在許多重要的硬件規格上都是獨一無二的。基于徹底的目視檢查，該DMCB模型包含幾個獨特的元素，包括：

三個26針連接器

一個40針連接器

2個LED指示燈

表面貼裝復位開關

共19個跳線

安裝程序可以使用DS200DMCBG1AKG上的跳線來更改電路板的行為。出廠時隨附的原裝電路板隨附的手冊描述了跳線以及它們?nèi)绾胃淖冸娐钒宓男袨?，盡管如前所述，本手冊的在線可用性相對有限。雖然此DS200 DMCB的底板上確實存在可定制的硬件跳線，但并非所有跳線都可以由安裝人員或合格的服務人員移動。此模塊底板上的一些跳線是硬接線跳線，僅用于制造工廠的測試目的。GE Fanuc或原始電路板隨附的其他系列手冊也將識別這些跳線。

雖然該型號在互聯網上的手冊信息通常很少，但該電路板底板上的一系列工廠發布的標簽可以揭示其他重要的硬件規格.例如，該DS200DMCBG1AKG型號在電路板頂部貼有“IOS主控”功能描述。除了這個最初的一般描述性標簽外，該型號的DMCG PCB還貼有各種標簽，包括C-ESS、V 5和美國通用電氣，以及DMCG表面配備的數百個繼電器和眾多插頭的標準行業標簽。

 >>>>>型號:DS200DMCBG1AKG 處理器板 表面貼裝復位開關

【英文介紹】

DS200DMCBG1AKG Technical specifications

Manufacturer GE General Electric

Series EX2000

Part number DS200DMCBG1AKG

The IOS DUP processor board DS200DMCBG1AKG is a GE IOS processor board manufactured by trusted industrial retailer General Electric. The relative scarcity of instructional manual materials on the Internet makes it difficult to distinguish between specific manufacturers and series, however

Hardware tips and specifications

Like many GE Industrial Systems Fanuc products, the GE IOS DUP processor board DS200DMCBG1AKG is unique in a number of important hardware specifications. Based on a thorough visual inspection, the DMCB model contains several unique elements, including:

Three 26-pin connectors

A 40 pin connector

2 LED indicators

Surface mount reset switch

A total of 19 jumpers

The installer can use jumpers on the DS200DMCBG1AKG to change the behavior of the board. The manual that comes with the original board shipped with the factory describes the jumpers and how they change the behavior of the board, although as mentioned earlier, the online availability of this manual is relatively limited. While customizable hardware jumpers do exist on the baseboard of this DS200 DMCB, not all of them can be moved by installers or qualified service personnel. Some of the jumpers on the baseboard of this module are hardwired jumpers and are only used for testing purposes in manufacturing plants. These jumpers will also be identified in the GE Fanuc or other series manuals that came with the original circuit board.

While manual information for this model on the Internet is usually sparse, a series of factory-issued labels on the board's backboard can reveal other important hardware specifications. For example, the DS200DMCBG1AKG model has the "IOS Master" function description posted on the top of the board. In addition to this initial general descriptive label, the DMCG PCB for this model is also labeled with various labels, including C-ESS, V 5, and US General Electric, as well as the standard industry label for hundreds of relays and numerous plugs equipped with the DMCG surface.
