>>>型號:AS-BDEP-218 離散輸入模 用于工業自動化和控制系統

【功能描述】

AS-BDEP-218是一款離散輸入模塊，通常用于為子系統或外部輸入創建輸入端口，將輸入信號從系統的外部引入到內部。這款模塊具有廣泛的應用場景，特別是在工業自動化和控制系統領域。

AS-BDEP-218模塊在緊急停止被激活時，能夠使DSU停止并打開主接觸器。當緊急停止功能停用，DSU復位后，模塊能夠恢復正常工作。此外，該模塊還包含接地電流功能控制板（DSSB），

用于測量二極管供電單元的輸入電流，并持續監測相電流的總和。

在電源及保護方面，AS-BDEP-218模塊采用雙電源冗余輸入，電壓范圍為DC(9-36)V，典型工作電壓為DC24V，功耗小于4W。該模塊還具備DC1500V電壓隔離以及反接保護功能，采用工業

端子接口。在出現故障時，如光纖鏈路故障或電源故障，模塊能夠輸出告警信號，觸點容量為DC48V/1A，同樣采用工業端子接口。

在機械特性方面，AS-BDEP-218的外形尺寸為132mm×105mm×52mm，外殼防護等級為IP30，采用波浪紋鋁制加強機殼。模塊采用35mmDIN導軌安裝方式，凈重為800g。其工作環境溫度

范圍為-10-70℃，相對濕度應≤90%（無冷凝），存放溫度范圍為-40～80℃。

>>>>型號:AS-BDEP-218 離散輸入模 用于工業自動化和控制系統

【英文介紹】

AS-BDEP-218 is a discrete input module typically used to create input ports for subsystems or external inputs, bringing input signals from the outside of the system into the inside. This module

has a wide range of application scenarios, especially in the field of industrial automation and control systems.

The AS-BDEP-218 module is capable of stopping the DSU and opening the main contactor when the emergency stop is activated. After the emergency stop function is disabled and the DSU is reset,

 the module can resume normal operation. In addition, the module includes a Ground Current Function Control Board (DSSB), which measures the input current of the diode-powered unit and

continuously monitors the sum of the phase current.

In terms of power supply and protection, the AS-BDEP-218 module uses dual power supply redundant inputs, the voltage range is DC(9-36)V, the typical operating voltage is DC24V, and the power

 consumption is less than 4W. The module also has DC1500V voltage isolation and reverse connection protection, using industrial terminal interfaces. When a fault occurs, such as a fiber link fault o

r a power supply fault, the module can output alarm signals. The contact capacity is DC48V/1A, and the industrial terminal is also used.

In terms of mechanical characteristics, the AS-BDEP-218 has an external dimension of 132mm×105mm×52mm, the housing protection class is IP30, and the case is reinforced with wavy aluminum.

 The module is mounted with 35mmDIN rail and has a net weight of 800g. The operating temperature range is -10-70 ° C, the relative humidity should be less than 90% (no condensation), and the

 storage temperature range is -40 ~ 80 ° C.
