>>>型號:1756-LSC8XIB8I/A 計數器模塊 用于計數、監測和控制應用 支持輸入脈沖信號的計數

【功能描述】

1756-LSC8XIB8I/A是一個計數器模塊，通常用于計數、監測和控制應用中。它是ControlLogix系列控制器的一部分，具有多個計數通道，可以獨立配置以適應不同的計數應用。

1756-LSC8XIB8I/A該模塊支持輸入脈沖信號的計數，通常用于監測旋轉編碼器、傳感器或其他脈沖信號源的計數。它通常包括8個計數通道，用于監測和記錄輸入信號的計數值。此外，該模塊支持高速計數，

以便實時監測快速運動或快速計數的應用。

1756-LSC8XIB8I/A該模塊是一個具有標準輸入或計數器控制功能的八輸入點、八計數器模塊，提供24V高速直流隔離的灌/灌輸入。它具備大計數頻率為40 kHz的計數器，并且計數器返回累加計數、瞬時頻率、

平均頻率、瞬時脈沖寬度和平均脈沖寬度。它是一個31位計數器，計數范圍為0到2,147,483,648。

>>>>型號:1756-LSC8XIB8I/A 計數器模塊 用于計數、監測和控制應用 支持輸入脈沖信號的計數

【英文介紹】

The 1756-LSC8XIB8I/A is a counter module commonly used in counting, monitoring and control applications. It is part of the ControlLogix family of controllers and features multiple counting channels that can

be configured independently to suit different counting applications.

1756-LSC8XIB8I/A This module supports the counting of input pulse signals and is commonly used to monitor the counting of rotary encoders, sensors or other pulse signal sources. It usually includes eight c

ounting channels for monitoring and recording the count value of the input signal. In addition, the module supports high-speed counting for real-time monitoring of fast motion or rapid counting applications.

1756-LSC8XIB8I/A This module is an eight-point, eight-counter module with standard input or counter control functions, providing 24V high-speed DC isolated injection/infusion. It has a counter with a large

 count frequency of 40 kHz, and the counter returns cumulative count, instantaneous frequency, average frequency, instantaneous pulse width, and average pulse width. It is a 31-bit counter with a count range

from 0 to 2,147,483,648.

>>>>型號:1756-LSC8XIB8I/A 計數器模塊 用于計數、監測和控制應用 支持輸入脈沖信號的計數
