>>>型號:1336-BDB-SP17D PCB柵極驅動器板 用于PCB柵極驅動器板

【功能描述】

1336-BDB-SP17D是一款專為與1336 PLUS、FORCE、IMPACT和PLUS II驅動器配合使用的PCB柵極驅動器板。它位于1336驅動器的正下方主控板，主要目的是放大來自基礎驅動板電源板的低電流輸入。

1336-BDB-SP17D驅動板設計用于460V AC（三相）工作電壓，其板額定功率為40HP。它配備了7個跳線連接器，標記為J2、J6、J7、J8、J9、J10和J13，這些跳線連接器用于連接1336驅動器的主控制板。

此外，該驅動板還有名為T4、T6和T7的部件，與TB4一起用作24V DC輔助輸入。

安裝方面，這款柵極驅動器板可以按照特定的步驟安裝在變頻器的主控制板安裝板上。這樣的設計不僅便于安裝和維護，而且能夠確保電機或其他電氣設備的精確和高效運行。

總的來說，1336-BDB-SP17D是一款功能強大、性能穩定的柵極驅動板，適用于各種PCB柵極驅動器板。

>>>>型號:1336-BDB-SP17D PCB柵極驅動器板 用于PCB柵極驅動器板

【英文介紹】

The 1336-BDB-SP17D is a PCB gate driver board designed for use with the 1336 PLUS, FORCE, IMPACT and PLUS II drivers. It is located directly below the main control board of the 1336 driver and its main purpose is

 to amplify the low current input from the power board of the base driver board.

The 1336-BDB-SP17D driver board is designed for 460V AC (three-phase) operating voltage and its board power rating is 40HP. It is equipped with seven jumper connectors, labeled J2, J6, J7, J8, J9, J10, and J13, which

 are used to connect the main control board of the 1336 drive. In addition, the drive board has components called T4, T6 and T7, which together with the TB4 are used as 24V DC auxiliary inputs.

In terms of installation, the grid driver board can be installed on the main control board mounting board of the inverter in accordance with specific steps. Such a design is not only easy to install and maintain, but also e

nsures accurate and efficient operation of motors or other electrical equipment.

Overall, the 1336-BDB-SP17D is a powerful and stable gate driver for a wide range of industrial automation control systems.
