>>>型號:1769-IF8-CC 模擬量輸入模塊 用于工業自動化和控制系統 具有8個輸入通道
【功能描述】
1769-IF8-CC是一款CompactLogix系列模擬量輸入模塊。該模塊在工業自動化系統中發揮著至關重要的作用，主要用于接收和轉換來自傳感器和執行器的模擬信號，以便進行精確的控制和監測。
1769-IF8-CC該模塊具有8個輸入通道，每個通道都支持差分和單端接線，提供了靈活的連接方式。同時，該模塊支持多種信號類型，包括0-20mA、4-20mA、+/10VDC、1-5VDC、0-5VDC和0-10VDC，
使其能夠適應多種不同的傳感器和執行器類型。
在電氣性能方面，1769-IF8-CC模塊具有出色的性能參數。其供電距離額定值為8個模塊，確保模塊能夠接收到適當的背板電源。此外，該模塊還具有高分辨率（16位）和高速采樣速率（10ms），能夠精
確捕捉和轉換模擬信號。
該模塊還具備強大的隔離功能。它支持逐通道隔離，確保通道間和系統地面之間的隔離，從而提高了系統的抗干擾能力和穩定性。同時，該模塊還具有防護等級為NEMA/UL Type 1、3、4、12、13的標準，
也可選NEMA/UL Type 4X、IP66/67，適用于各種惡劣的工業環境。
在精度方面，1769-IF8-CC模塊對電壓信號和電流信號的總體精度分別高達+/-0.2%和0.35%，能夠滿足大多數工業自動化應用的需求。同時，該模塊還具有出色的穩定性和可靠性，能夠在長時間運行過程
中保持穩定的性能。
綜上所述，1769-IF8-CC是一款功能強大、性能穩定的模擬量輸入模塊。它以其靈活的連接方式、高分辨率、高速采樣速率和強大的隔離功能等特點，在工業自動化領域中發揮著重要作用。無論是新建系統
還是升級改造現有系統，該模塊都能為用戶提供高效、可靠的自動化解決方案。
>>>>型號:1769-IF8-CC 模擬量輸入模塊 用于工業自動化和控制系統 具有8個輸入通道
【英文介紹】
The 1769-IF8-CC is a CompactLogix series analog input module. The module plays a vital role in industrial automation systems, mainly for receiving and converting analog signals from sensors and
actuators for precise control and monitoring.
1769-IF8-CC The module has 8 input channels, each of which supports differential and single-ended wiring, providing a flexible connection. At the same time, the module supports a variety of signal
types, including 0-20mA, 4-20mA, +/10VDC, 1-5VDC, 0-5VDC, and 0-10VDC, enabling it to accommodate a wide range of different sensor and actuator types.
In terms of electrical performance, the 1769-IF8-CC module has excellent performance parameters. Its power supply distance rating is 8 modules, ensuring that the module can receive the appropriate
backplane power. In addition, the module has a high resolution (16-bit) and a high sampling rate (10ms), enabling accurate capture and conversion of analog signals.
The module also has a powerful isolation function. It supports channel-by-channel isolation to ensure isolation between channels and between the system ground, thus improving the anti-interference
ability and stability of the system. At the same time, the module also has the protection level of NEMA/UL Type 1, 3, 4, 12, 13 standards, also optional NEMA/UL Type 4X, IP66/67, suitable for a variety of
harsh industrial environments.
In terms of accuracy, the 1769-IF8-CC module has an overall accuracy of +/-0.2% for voltage signals and 0.35% for current signals, respectively, which can meet the needs of most industrial automation
applications. At the same time, the module also has excellent stability and reliability, which can maintain stable performance during long-term operation.
To sum up, the 1769-IF8-CC is a powerful and stable analog input module. It plays an important role in the field of industrial automation with its flexible connection mode, high resolution, high sampling
rate and powerful isolation function. Whether it is to build a new system or upgrade an existing system, the module can provide users with efficient and reliable automation solutions.
