>>>>>型號:NI-9853 高速控制器局域網接口模塊
【功能描述】
NI-9853是新型高速控制器局域網接口模塊，專門為其高性能CompactRIO平臺設計。
該模塊具備兩個CAN接口，每個接口都配備9引腳的公口DSUB連接器，以便于連接到CAN總線。其端口上的CAN_H和CAN_L引腳專用于連接CAN總線信號，這些信號應使用雙絞線進行連接。
NI-9853模塊的主要特性還包括其端口設計，每個端口都帶有兩個公用引腳（COM），這些引腳在內部連接到模塊的隔離參考地，并用作CAN_H和CAN_L的參考地。此外，每個端口還配有一
個可選的屏蔽引腳（SHLD），用于在噪聲環境下連接屏蔽式CAN電纜，從而增強信號完整性和EMC性能。
模塊的設計使得它特別適用于汽車及工業應用，因為它可以插入任何CompactRIO機箱中。此外，NI-9853僅與CompactRIO系統兼容，其設計是為了在CompactRIO上開發應用程序時與NI-RIO
驅動結合使用。它還適用于使用LabVIEW FPGA模塊進行基于FPGA的底層控制和觸發應用程序編程，并且是LabVIEW FPGA模塊對CAN幀進行字節級操作的理想驅動。
綜上所述，NI-9853是一款功能強大、設計精良的高速CAN接口模塊，專為滿足高性能CompactRIO平臺的需求而設計。
>>>>>型號:NI-9853 高速控制器局域網接口模塊
【英文介紹】
NI-9853 is a new high-speed controller LAN interface module designed specifically for its high-performance CompactRIO platform.
The module has two CAN interfaces, each equipped with a 9-pin male DSUB connector for easy connection to the CAN bus. The CAN_H and CAN_L pins on its ports are dedicated to connecting
CAN bus signals, which should be connected using twisted pair cables.
Key features of the NI-9853 module also include its port design, with each port having two common pins (COM) that are internally connected to the isolated reference points of the module and
used as reference points for CAN_H and CAN_L. In addition, each port has an optional shielded pin (SHLD) for connecting shielded CAN cables in noisy environments, enhancing signal integrity and EMC performance.
The design of the module makes it particularly suitable for automotive and industrial applications, as it can be inserted into any CompactRIO case. In addition, the NI-9853 is only compatible with
CompactRIO systems and is designed to be used in conjunction with NI-RIO drivers when developing applications on CompactRIO. It is also suitable for low-level FPGA-based control and trigger
application programming using LabVIEW FPGA module, and is an ideal driver for byte level manipulation of CAN frames by LabVIEW FPGA module.
To sum up, the NI-9853 is a powerful and well-designed high-speed CAN interface module designed specifically to meet the needs of high-performance CompactRIO platforms.
