6ES7135-0HF01-0XB0 |5SHY5045L0020|模擬電子模塊|

6ES7135-0HF01-0XB0 是模擬電子模塊，用于 ET 200B 分布式 I/O 系統，提供 4 個模擬輸出通道，可以是電壓或電流輸出。這個模塊的電壓輸出范圍是 0 到 10V 和 -10V 到 +10V，具有 11 位的分辨率，并且具備短路保護功能。電流輸出范圍是 0 到 20mA 和 4 到 20mA。該模塊還具備多種其他功能和規格，適用于多種工業應用場景

PN結的單向?qū)щ娦?/span>

當外加電壓使PN結中P區的電位高于N區的電位，稱為加正向電壓，簡稱正偏;反之稱為加反向電壓，簡稱反偏。

(1)PN結加正向電壓時:低電阻、大的正向擴散電流。

(2)PN結加反向電壓時:高電阻、很小的反向漂移電流。

當PN結處于正向偏置時，擴散運動使多數載流子穿過PN結，在對方區域PN結附近有高于正常情況時的電荷累積。存儲電荷量的大小,。

取決于PN結上所加正向電壓值的大小。離結越遠，由于空穴與電子的復合，濃度將隨之減小。

若外加正向電壓有一增量V，則相應的空穴(電子)擴散運動在結的附近產生一電荷增量^Q，二者之比^Q/^V為擴散電容Cd.

6ES7135-0HF01-0XB0 is an analog electronics module for ET 200B distributed I/O systems that provides 4 analog output channels, which can be voltage or current outputs. The module has a voltage output range of 0 to 10V and -10V to +10V, an 11-bit resolution, and short-circuit protection. Current output ranges are 0 to 20mA and 4 to 20mA. The module also has a variety of other features and specifications for a variety of industrial application scenarios

Unidirectional conductivity of PN junction

When the applied voltage makes the potential in the P region of the PN junction higher than the potential in the N region, it is called the positive voltage, referred to as positive bias; On the contrary, it is called adding reverse voltage, referred to as reverse bias.

(1)PN junction with forward voltage: low resistance, large forward diffusion current.

(2)PN junction with reverse voltage: high resistance, small reverse drift current.

When the PN junction is in forward bias, the diffusion motion causes most carriers to pass through the PN junction, and there is higher than normal charge accumulation near the PN junction in the other region. The magnitude of the stored charge,.

It depends on the value of the forward voltage applied to the PN junction. The further away from the junction, the concentration will decrease due to the recombination of holes and electrons.

If the applied forward voltage has an incremental V, then the corresponding hole (electron) diffusion motion produces an incremental charge ^Q near the junction, the ratio of the two ^Q/^V is the diffusion capacitance Cd.
