【功能描述】

通用電氣 （GE） 開發了iS200TREGH1BEC 保護終端板，作為 Mark VI 系列的一個組件，用于燃?xì)?蒸汽輪機管理和自動化。IS200TREGH1BEC是印刷電路板或PCB的一個版本。Mark VI 系列的 IS200TREGH1BEC 和其他組件是更大的 Mark 系列渦輪機控制裝置的一部分。

IS200TREGH1BEC PCB是矩形的。IS200TREGH1BEC上最突出的組件是兩 （2） 個接線端子和兩 （2） 個繼電器或接觸器。接線端子是黑色的，尺寸很大。它們垂直放置在IS200TREGH1BEC的左邊緣。IS200TREGH1BEC上的繼電器在IS200TREGH1BEC頂部的中心垂直配對。這些繼電器大多是紅色的，它們的頂部有黃色和黑色的部分。緊挨著左側這些繼電器的是兩 （2） 個紅色圓形 MOV 或金屬氧化物壓敏電阻。整個IS200TREGH1BEC中都有幾個小尺寸的黃色常亮電容器，主要位于電路板的下半部分。IS200TREGH1BEC的右邊緣襯有三 （3） 個中型插孔連接器端口，名稱為 JZ1、JY1 和 JX1。這些連接器端口中多了三 （3） 個，它們比其他連接器端口?。ù蠹s是其他連接器的一半），已排在這些其他連接器端口的左側。較小的連接器端口已由名稱 JZ5、JY5 和 JX5 標識。三 （3） 個黑色可變電阻器或電位計位于IS200TREGH1BEC的右上方。

>>>>>型號:IS200TREGH1BEC 保護終端板 渦輪機控制裝置

【英文介紹】

General Electric (GE) has developed the iS200TREGH1BEC protected terminal Board as a component of the Mark VI series for gas/steam turbine management and automation. IS200TREGH1BEC is a version of a printed circuit board or PCB. The IS200TREGH1BEC and other components of the Mark VI series are part of a larger Mark series turbine control unit.

IS200TREGH1BEC PCB is rectangular. The most prominent components on the IS200TREGH1BEC are the two (2) terminals and two (2) relays or contactors. The terminals are black and large. They are placed vertically on the left edge of the IS200TREGH1BEC. The relays on the IS200TREGH1BEC are vertically paired at the center of the top of the IS200TREGH1BEC. Most of these relays are red, and they have yellow and black sections on top. Immediately next to these relays on the left are two (2) red round MOV or metal oxide varistors. Throughout the IS200TREGH1BEC there are several small sized yellow steady on capacitors, mainly located in the bottom half of the circuit board. The right edge of the IS200TREGH1BEC is lined with three (3) medium jack connector ports, named JZ1, JY1 and JX1. There are three (3) more of these connector ports, which are smaller than the other connector ports (about half the size of the other connector ports) and have been lined up to the left of these other connector ports. Smaller connector ports have been identified by the names JZ5, JY5, and JX5. Three (3) black variable resistors or potentiometers are located on the upper right of the IS200TREGH1BEC.
