【功能描述】
制造商:霍尼韋爾
產品編號:51196655-100
產品類型:TDC 3000電源模塊
51196655-100產生了當時控制系統領域的許多重要成果，如冗余控制器、冗余控制網絡(DH-Data Hiway)、人機界面等。
根據分布原則，整個TDC2000的基本功能分布特點如下:控制網絡采用單層冗余結構；操作站負責操作和數據存儲；不同的控制器實現不同的過程控制等等。這種基本的功能分配仍被一些DCS的控制廠商所采用。
2.作為最典型的DCS系統，51196655-100進一步體現了分散控制的理念，具有以下主要特點:
為滿足大規模生產的需要，采用兩層控制網絡架構，每個LCN可以連接10個UCN，每個UCN可以連接32對冗余控制器。64個lcn也可以通過NG連接。
三層控制平臺
1)PMX實現最基本的回路調節、邏輯聯動、順序控制和復雜回路控制。
2)AM實現高級控制
3)VAX優化控制
引入緊急停車系統SM，實現安全生產保障。
>>>>>型號:51196655-100 電源模塊 控制網絡采用單層冗余結構
【英文介紹】
Manufacturer: Honeywell
Product Number :51196655-100
Product type :TDC 3000 power module
51196655-100 produced many important achievements in the field of control systems at the time, such as redundant controllers, redundant control networks (DH-Data Hiway), human-machine interfaces, and so on.
According to the distribution principle, the basic function distribution characteristics of the whole TDC2000 are as follows: the control network adopts single-layer redundancy structure; The operation station is responsible for operation and data storage; Different controllers realize different process control and so on. This basic function allocation is still used by some DCS control vendors.
2. As the most typical DCS system, 51196655-100 further reflects the concept of decentralized control, with the following main features:
In order to meet the needs of large-scale production, a two-layer control network architecture is adopted. Each LCN can connect 10 UCNs, and each UCN can connect 32 pairs of redundant controllers. 64 LCNS can also be connected via NG.
Three-layer control platform
1)PMX implements the most basic loop regulation, logical linkage, sequence control and complex loop control.
2)AM to achieve advanced control
3)VAX optimization control
Emergency shutdown system SM is introduced to ensure safe production.
