>>>>>型號:IS200EPSMG1AED 激勵器PT/CT板 提供以太網功能

【功能描述】

該IS200EPSMG1AED由通用電氣制造，作為其Mark VI Speedtronic系統的一部分，該系統設計用于控制工業燃?xì)廨啓C(jī)/蒸汽輪機。Speedtronic系列于1960年代后期開始生產Mark I。從那時起，Speedtronic發布的每個系統都比以前的設計不斷改進。Mark VI提供以太網功能、基于PC的操作界面以及預裝的專有軟件，如CIMPLICITY和GE Toolbox。操作界面是一個非必要的組件，可以隨時重新初始化，而不會影響系統的控制。

IS200EPSMG1AED是激勵器PT/CT板。它包括2個用于發電機PT電壓的三相輸入和2個用于發電機CT電壓的電流輸入。還有一個模擬輸入。

IS200EPSMG1AED的物理設計如下：它沿其前緣放置了三個端子排，包括一個24位接線板和兩個4位接線板。后邊緣有三個垂直插針連接器。它們被標記為J315、J305和J308。該板有12個測試點、一個跳線開關、2個環形變壓器、4個安裝在框架中的變壓器以及電阻器、電容器和金屬氧化物壓敏電阻（MOV）。

 >>>>>型號:IS200EPSMG1AED 激勵器PT/CT板 提供以太網功能

【英文介紹】

IS200EGDMH1AFF is an exciter field grounding detection module, which is the functional abbreviation of EGDM.

During the installation, the module will be installed on the backplane of the excitation power supply or the terminal block of the exciter. It is used to detect the ground status of the excitation magnetic field and output the detection result to the control system or display instrument to realize the ground protection and control of the excitation.

It should be noted that the above information is for reference only, if necessary, it is recommended to consult professional and technical personnel.

The difference between IS200EGDMH1ADF and IS200EGDMH1AFF is that the former is the excitation field grounding detection module, and the latter is the excitation field grounding detection module.

During the installation process, the former is installed on the backplane of the excitation power supply or the terminal block of the exciter, which is used to detect the ground state of the excitation magnetic field, and output the detection result to the control system or display instrument to realize the ground protection and control function of the exciter. The latter is mounted on the excitation power backplane rack, close to the EPSM module, and operates on stand-alone systems, which require one EGDM, and redundant systems, which require three EGDM modules.
