>>>>>型號:IS200TDBTH6ACD 分立單工板的器件 渦輪機系統

【功能描述】

IS200TDBTH6ACDCD是一種稱為分立單工板的器件。這是通用電氣或通用電氣制造的印刷電路板或PCB的一種形式。該IS200TDBTH6ACDCD是通用電氣用于蒸汽和燃?xì)廨啓C(jī)控制的Mark VI系列的組件設備。該系列是構成Mark系列的幾個系列之一。這些系統用于控制全球各行各業的渦輪機系統。

該IS200TDBTH6ACDCD突出地具有12個大型黑色電位器的集合，這些電位器也稱為可變電阻器。電位計排列成三（3）個水平行，每個行四個組件。電位計的兩側放置著一個長方形的灰色元件。IS200TDBTH6ACDCD的下半部分被幾排非常小的組件占據。兩（2）排長長的圓形紅色元件，稱為MOV或金屬氧化物壓敏電阻，排列在IS200TDBTH6ACDCD的左側。在靠近中心的IS200TDBTH6ACDCD的最底部是一個帶有三（3）個端口的白色小連接器。此連接可用于將其他設備連接到IS200TDBTH6ACDCD。幾個小的集成電路可以放置在IS200TDBTH6ACDCD的上半部分。其中一些在中心水平排列，其他在右上角垂直對齊。在集成電路的IS200TDBTH6ACDCD中心有一（1）個黃色小電容器。兩（2）個黃色小電阻器位于IS200TDBTH6ACDCD底部，中間有一（1）條黑色條紋。

 >>>>>型號:IS200TDBTH6ACD 分立單工板的器件 渦輪機系統

【英文介紹】

The IS200TDBTH6ACDCD is a device called a discrete simplex board. This is a form of printed circuit board or PCB manufactured by General Electric or GE. The IS200TDBTH6ACDCD is a component of GE's Mark VI series for steam and gas turbine control. The series is one of several that make up the Mark series. These systems are used to control turbine systems in a wide range of industries worldwide.

The IS200TDBTH6ACDCD prominently features a collection of 12 large black potentiometers, which are also known as variable resistors. The potentiometers are arranged in three (3) horizontal rows of four components each. A rectangular gray element is placed on either side of the potentiometer. The lower half of the IS200TDBTH6ACDCD is occupied by several rows of very small components. Two (2) rows of long round red elements, called MOV or metal oxide varistors, are arranged on the left side of the IS200TDBTH6ACDCD. At the very bottom of the IS200TDBTH6ACDCD near the center is a small white connector with three (3) ports. This connection can be used to connect other devices to the IS200TDBTH6ACDCD. Several small integrated circuits can be placed in the top half of the IS200TDBTH6ACDCD. Some of them are aligned horizontally in the center and others are aligned vertically in the upper right corner. There is one (1) small yellow capacitor in the center of the IS200TDBTH6ACDCD of the integrated circuit. Two (2) small yellow resistors are located at the bottom of the IS200TDBTH6ACDCD with one (1) black stripe in the middle.

>>>>>型號:IS200TDBTH6ACD 分立單工板的器件 渦輪機系統
